Rolling Stock

• All the components are integrally built in a shroud cover.
• Moreover, this system that can be easily detached from a car body is excellent in maintainability.
• Operation of this system requires power supply of 24 V DC, compressed air and fresh water.
• Flushing of a toilet requires an amount of water as small as 0.5 liter per operation
• The bowl made of stainless steel is effectively rinsed by water sprayed from nozzles installed at the upper side of the bowl even consuming a small amount of water.

Various kinds of accessories for the GOCO-EVAC vacuum compact toilet system are widely available.

This vacuum compact toilet is an extremely sanitary toilet system that is light, small-sized and effective for space-saving.
Since no chemicals are used, we can say it is an vironment friendly toilet.
Each toilet unit has an independent vacuum system to enable individual operation.
As shown by the name "Compact Toilet," it is also one of the advantages that the main components compactly housed in a unit enable easy inspection and maintenance.

Compact and lightweight urinal made of FRP.

Improved maintenance and dismounting ability by installing the inspection opening at lower part of toilet unit for easy access to pipes.

The basic concept for the vacuum type toilet is to make toilets more sanitary and environmentally friendly. The toilet chamber is perfectly insulated from the odor coming from the bowl. The bowl is rinsed up effectively with minimal volume of water and the sewage is carried away into the sewage tank by the powerful force of vacuum. As one of the toilet systems most suitable for vehicles, the vacuum type toilet is rapidly coming into wide use.

The Electric Water Supply Equipment, which integrates a water tank and a feed pump to supply clean water for use on board a train, is very convenient water supply equipment.
Compared to the conventional equipment, it offers a much easier loading onto vehicles and maintenance. The tank is made of stainless steel, which can flexibly meet the characteristic requirements of individual vehicles and variation of storage capacity.

This heater is for operating room of an electric train and,although compact in design produces superior performance.
Air flow velocity and temperature can be adjusted and it is a rather new type of air heater which can be used both in summer and winter. Cool and warm air are supplied as needed.
Another type of heater unit is also available, which can be used as a defroster for the windshield of an operating room to prevent freezing.
There are various types of heaters such as upright, wall mounted, set-into the wall or under the floor, and specific
designs and manufacture are also available on request.
Besides the above types of electric heater and defroster,
we can design and manufacture special types according to your specifications.

For the engines preheater, diesel oil or kerosene is used to raise the temperature of the engine's. Using the hot water, the engine is preheated for smooth start even in winter as well as to prevent wear. The preheater is also used to heat the compartment.
Furthermore, it can be used to maintain or rise the water temperature together with the hot water heating unit.

The hot water heating units are of the hot air blowing type.
The photograph shows the radiator unit which is arranged according to the size of a large-sized passenger quarter of the rolling stock and buses. The unit with a defroster is available to install a heater together.

We have wipers which are operated by electric. It definitely helps safe drive.
